Carbon Dioxide Sensor
CO2S-10
The CO2S-10 monitors carbon dioxide concentration, temperature and relative humidity, providing a combined view of environmental conditions. It transmits readings over wanwave LPWAN and offers a listed CO₂ resolution of 1 ppm, with BLE available for local configuration.
Powered by a 3.6 V lithium thionyl chloride battery, the sensor has a battery life of three years and transmission power below 25 mW. Its compact, IP67-rated enclosure measures 125 × 67 × 50 mm and weighs 160 g.
MEASUREMENTS
Carbon dioxide (CO₂), temperature, relative humidity
COMMUNICATION
wanwave LPWAN
POWER SUPPLY
3.6V LiSOCl₂ battery
ENCLOSURE RATING
IP67
Applications
Agriculture
Track temperature and humidity to support healthy crops and resilient operations.
Explore solution →
Buildings
Monitor indoor conditions to support occupant comfort and operational efficiency.
Explore solution →
Museums
Help protect valuable collections with reliable environmental monitoring.
Explore solution →Technical specifications
| Model number | CO2S-10 |
|---|---|
| Measurements | Carbon dioxide (CO₂), temperature, relative humidity |
| Measurement accuracy | Carbon Dioxide (CO2): 1ppm Temperature: ±0.5°C Relative Humidity: ±1% |
| Communication interface | wanwave LPWAN |
| Configuration interface | Bluetooth |
| Power supply | 3.6V LiSOCl₂ battery |
| Enclosure rating | IP67 |
| Operating conditions | -10°C to +80°C |
| Dimensions | 125 × 67 × 50 mm |
| Weight | 160 g |
| Battery life & conditions | 3 years |
Connectivity & integration
CO2S-10 transmits carbon dioxide, temperature, and relative humidity readings over wanwave’s proprietary network through a compatible wanwave gateway. The gateway forwards the data to wanwave monitoring platforms or your existing IT systems. The sensor operates on battery power, and Bluetooth is used for configuration.
Documents
Product datasheet (PDF) →
