Multi-channel Pulse Counter
PLSC-2 / PLSC-4 / PLSC-6
The PLSC series counts pulses from connected meters and equipment and transmits data over wanwave LPWAN, helping teams monitor usage and activity remotely. Available with two, four or six channels, the PLSC-2, PLSC-4 and PLSC-6 support up to 500 pulses per second on each channel. Notifications are sent every 100 pulses, with periodic data updates at intervals of less than six hours.
Powered by a 3.6 V lithium thionyl chloride battery with a five-year battery life, the counters support long-term monitoring without an external power connection. All three variants share a compact, IP68-rated enclosure measuring 89 × 80 × 48 mm and weighing 255 g.
MEASUREMENTS
Pulse counts across 2, 4, or 6 channels, depending on model
COMMUNICATION
wanwave LPWAN
POWER SUPPLY
3.6V LiSOCl₂ battery
ENCLOSURE RATING
IP68
Applications
Technical specifications
| Model number | PLSC-2 / PLSC-4 / PLSC-6 |
|---|---|
| Measurements | Pulse counts across 2, 4, or 6 channels, depending on model |
| Measurement range | Maximal pulses per second: 500 on each channel Status change notification: Every 100 pulses Data update rate: < 6 hours |
| Communication interface | wanwave LPWAN |
| Power supply | 3.6V LiSOCl₂ battery |
| Enclosure rating | IP68 |
| Operating conditions | -40°C to +80°C |
| Dimensions | 89 × 80 × 48 mm |
| Weight | 255 g |
| Battery life & conditions | 5 years |
Connectivity & integration
PLSC counters collect pulses from compatible meters or equipment and transmit counts over wanwave’s proprietary network through a compatible gateway. The gateway forwards the data to wanwave monitoring platforms or your existing IT systems. Models provide 2, 4, or 6 input channels. The counter operates on battery power; connected equipment must provide a compatible pulse output.
Documents
Product datasheet (PDF) →
