Standalone Perimeter Sensor
VFS-10
wanwave’s electronic fence sensors are designed to create a virtual perimeter. When an individual, group, or vehicle crosses the designated boundary, the system uses advanced sensors and algorithms to detect the breach.
The information is transmitted wirelessly to monitoring systems via a secure wanwave communication channel. This ensures immediate action can be taken by border patrol or security personnel.
MEASUREMENTS
Perimeter intrusion detection
COMMUNICATION
wanwave LPWAN
POWER SUPPLY
3.6V LiSOCl₂ battery
ENCLOSURE RATING
IP67
Applications
Technical specifications
| Model number | VFS-10 |
|---|---|
| Measurements | Perimeter intrusion detection |
| Measurement accuracy | For 5 m section: ≤ 1 m wide For 25 m section: ≤ 1.5 m wide For 50 m section: ≤ 2 m wide |
| Communication interface | wanwave LPWAN |
| Configuration interface | Bluetooth |
| Power supply | 3.6V LiSOCl₂ battery |
| Enclosure rating | IP67 |
| Operating conditions | -40°C to +80°C |
| Dimensions | 250 × 60 × 60 mm |
| Weight | 1 kg |
| Battery life & conditions | 2 years |
Connectivity & integration
VFS-10 transmits intrusion events over wanwave’s proprietary network through a compatible wanwave gateway to the monitoring or security platform. The sensor operates on battery power, and Bluetooth is used for configuration. Gateway power and uplink requirements depend on the selected model.
