Concrete Monitoring Sensor
CMS-10
The CMS-10 measures concrete temperature and transmits readings over wanwave LPWAN, supporting remote tracking of temperature conditions during concrete monitoring. It provides a listed measurement accuracy of ±0.12°C, with BLE available for local configuration.
Powered by a 3.6 V lithium thionyl chloride battery, the sensor transmits at below 25 mW. Its IP68-rated enclosure measures 192 × 90 × 40 mm and weighs 350 g, with an ambient operating temperature range of -40°C to +80°C.
MEASUREMENTS
Temperature
COMMUNICATION
wanwave LPWAN
POWER SUPPLY
3.6 V LiSOCl₂ battery
ENCLOSURE RATING
IP68
Applications
Technical specifications
| Model number | CMS-10 |
|---|---|
| Measurements | Temperature |
| Measurement accuracy | ±0.12°C |
| Communication interface | wanwave LPWAN |
| Configuration interface | Bluetooth |
| Power supply | 3.6 V LiSOCl₂ battery |
| Enclosure rating | IP68 |
| Operating conditions | -40°C to +80°C |
| Dimensions | 192 × 90 × 40 mm |
| Weight | 350 g |
| Battery life & conditions | 1.5 years |
Connectivity & integration
Transmits temperature readings over wanwave LPWAN with transmission power below 25 mW. Requires wanwave gateway coverage. BLE is used for local configuration.
Documents
Product datasheet (PDF) →
