Ammonia Sensor
NH3S-10
The NH3S-10 measures ammonia concentration and transmits readings over wanwave LPWAN, supporting remote monitoring of conditions where ammonia may be present. It has a specified measurement range of 0–50 ppm and a resolution of 0.5 ppm, with BLE available for local configuration.
Powered by a 3.6 V lithium thionyl chloride battery, the sensor has a battery life of three years and transmission power below 25 mW. Its compact, IP67-rated enclosure measures 125 × 67 × 50 mm and weighs 160 g.
MEASUREMENTS
Ammonia (NH₃) concentration
COMMUNICATION
wanwave LPWAN
POWER SUPPLY
3.6V LiSOCl₂ battery
ENCLOSURE RATING
IP67
Applications
Agriculture
Track temperature and humidity to support healthy crops and resilient operations.
Explore solution →
Buildings
Monitor indoor conditions to support occupant comfort and operational efficiency.
Explore solution →
Museums
Help protect valuable collections with reliable environmental monitoring.
Explore solution →Technical specifications
| Model number | NH3S-10 |
|---|---|
| Measurements | Ammonia (NH₃) concentration |
| Measurement accuracy | Max Detecting Concentration: 200ppm Sensitivity: (0.10±0.05)μA/ppm Resolution ratio: 0.5ppm |
| Measurement range | 0–50 ppm |
| Communication interface | wanwave LPWAN |
| Configuration interface | Bluetooth |
| Power supply | 3.6V LiSOCl₂ battery |
| Enclosure rating | IP67 |
| Operating conditions | -10°C to +80°C |
| Dimensions | 125 × 67 × 50 mm |
| Weight | 160 g |
| Battery life & conditions | 3 years |
Connectivity & integration
NH3S-10 transmits ammonia concentration readings over wanwave’s proprietary network through a compatible wanwave gateway. The gateway forwards the data to wanwave monitoring platforms or your existing IT systems. The sensor operates on battery power, and Bluetooth is used for configuration.
